Pioneer Ultimate Surge and Power Protection for Mini Split Systems is your go-to solution for safeguarding your investment against power surges and electrical noise. This rugged surge protector offers top-notch power surge protection with a lifetime warranty, ensuring peace of mind for your 110-120 VAC and 208-230 VAC systems. With an impressive energy dissipation of 1020 Joules and a maximum surge current of 100,000 Amps, it s built to handle the toughest conditions. Installation is a breeze, whether at the main panel or disconnect box, making it a low-cost, high-performance choice. Plus, its UL Listed, Type 2 device status and NEMA Type 3R enclosure guarantee reliability. Keep your mini split systems running smoothly with this essential electrical noise filter and enjoy the benefits of a lifetime warranty surge protector!
Pioneer Ultimate Surge and Power Protector

Protect your investment from power surges and electrical noise.
Limited LIFETIME Protection warranty
from the manufacturer For 110-120 VAC and 208-230 VAC Systems. Can be installed at the main panel or the disconnect box. Energy Dissipation: 1020 Joules Max Surge Current: 100,000 Amps
Features
- Protection for under-voltage & over-voltage events
- Easy installation
- Low cost, high performance
- Rugged, reliable
- UL Listed, Type 2 device
- NEMA Type 3R enclosure
Specifications
- Service Voltage: 120/240 volt, single phase
- Maximum Surge Current: 100,000 Amps
- Maximum Energy Dissipation: 1,020 Joules
- Installation Point: Electrical panel, electrical disconnect
- Diagnostics: Green light indicates surge suppression present
- AC Protection Modes: L-L, L-N, L-G, N-G
- Conduit Connection: 3/4”
- Dimensions: 5.0” L x 2.78” W x 2.16” D
| Title | Pioneer Ultimate Surge and Power Protection for Mini Split Systems |
|---|---|
| Brand | Pioneer |
| Category | Pioneer |
| SKU | ICM517 |
| Condition | new |
| UPC | 703158703945 |
| MPN | ICM517 |
