Pioneer Condensate Pump for Ductless Mini Split Systems, 5.8 Gal/H, 2m Lift, 100v-240v
Product Code: CP-RE-MWP-06
Rating: Be the first to write a review
Brand: Pioneer
Product Condition: New
Units in Stock: 10
Condensate Pump for Pioneer Mini Splits
WIRING
INSTRUCTIONS
Ultra-silent and compact mute box condensate drainage pump, perfect for installation in air conditioning units with limited available space. The compact size, low noise level, multiple placement options, and ease of installation makes this suitable for most projects. Can be wired alongside a shutoff alarm switch as a backup. Comes with all necessary components. Auto-shutoff capable. ETL certified for safety.
Features
Thermally Protected
Overflow Alarm Function
Max.water temperature 158°F
Automatic Tank Cleaning
Error Alarm
Anti-Mold Tank
TECHNICAL DATA
• Power Supply: 110-240VAC 50/60Hz ＜4W
• Max. water flow rate : 22L / 5.8 US Gal / H
• Max rec. head: 20m / 66ft
• Max.suction lift: 2m / 6.6ft
• Sound level: <19dB(A) @ 1m
• Rated: Continuous
• Class: II appliance
• Safety switch: 3A normally closed
• Max.water temperature :70℃ / 158°F
• Discharge Tube: 6mm ID
•IPX5 Protection
INSTRUCTIONS
Ultra-silent and compact mute box condensate drainage pump, perfect for installation in air conditioning units with limited available space. The compact size, low noise level, multiple placement options, and ease of installation makes this suitable for most projects. Can be wired alongside a shutoff alarm switch as a backup. Comes with all necessary components. Auto-shutoff capable. ETL certified for safety.
Features
Thermally Protected
Overflow Alarm Function
Max.water temperature 158°F
Automatic Tank Cleaning
Error Alarm
Anti-Mold Tank
TECHNICAL DATA
• Power Supply: 110-240VAC 50/60Hz ＜4W
• Max. water flow rate : 22L / 5.8 US Gal / H
• Max rec. head: 20m / 66ft
• Max.suction lift: 2m / 6.6ft
• Sound level: <19dB(A) @ 1m
• Rated: Continuous
• Class: II appliance
• Safety switch: 3A normally closed
• Max.water temperature :70℃ / 158°F
• Discharge Tube: 6mm ID
•IPX5 Protection
•LWH: 18.5cm X 3.6cm X 3.4 cm
•Thermal Protection: √
•Fully Potted: √
READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE OR SERVICE THE CONDENSATE PUMP. KNOW THE PUMP APPLICATION, LIMITATIONS AND POTENTIAL HAZARDS. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
•Thermal Protection: √
•Fully Potted: √
 |
 |
READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE OR SERVICE THE CONDENSATE PUMP. KNOW THE PUMP APPLICATION, LIMITATIONS AND POTENTIAL HAZARDS. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
