Bravo 4-Zone 23 SEER2 Mini Split Heat Pump (-13Β°F) WIFI, E-Star: 12.5 EER/10 HSPF (R32)

Free Shipping
In Stock R32 Bravo (4 Zone Special)

Experience ultimate comfort with the Bravo Quad Zone Split Heat Pump System! Designed to heat down to -13 F and cool just as efficiently, this powerhouse features a full DC-Inverter for optimal performance. With a remarkable SEER2 rating, it s not just efficient; it s smart too! The compact design and R32 refrigerant ensure you re making an eco-friendly choice without sacrificing comfort. This package includes a (-13 F) Heat Pump 4-Zone Outdoor Unit, and you can easily upgrade by adding indoor units through our dropdown options. Enjoy features like auto restart, auto defrost, and refrigerant leak protection, making it a reliable choice for your home. Whether you need to heat or cool multiple rooms, the Bravo four head split system has got you covered. Get ready to embrace personalized comfort like never before!

Your price
Description

Bravo 4-Zone Multi-Zone Heat Pump System
Bravo
Bravo 4-Zone Multi-Zone Heat Pump — 23 SEER2, R32
4 Zones 23 SEER2 12.5 EER 10 HSPF -13°F Min Heating R32 Refrigerant

Bravo 4-Zone Multi-Zone Heat Pump — Factory: Fujitsu General

23 SEER2 R32 -13°F Heating WiFi Included Factory: Fujitsu General Bluefin Protection

Efficient, compact, and built for versatility, the Bravo Milano Multi-Zone Outdoor Unit is the ideal foundation for personalized comfort across multiple indoor zones. With a high SEER2 rating, this 230V heat pump system offers impressive energy savings while maintaining steady, reliable performance throughout the seasons. Perfect for homes, apartments, or multi-room commercial spaces, this unit is well-suited for servicing areas such as bedrooms and a living room, a primary suite plus home office, or a studio paired with a shared space. This 4-zone special package ships with four wall mount indoor units (with remotes + WiFi) already selected and matched to the outdoor unit, and you can upgrade both the outdoor and indoor units via the drop-downs above.

The system features Full DC-Inverter technology, auto restart, auto defrost, and refrigerant leak protection, with heating operation down to -13°F and cooling down to -13°F. Its multi-zone capability allows you to pair different indoor unit types and capacities, giving you the flexibility to tailor comfort to each zone's unique needs. Using eco-friendly R32 refrigerant, this outdoor system delivers strong performance with a smaller environmental footprint. The 23 SEER2 / 12.5 EER / 10 HSPF figures shown are for the default configuration; upgrading the outdoor unit or indoor units changes those efficiency numbers.

βœ… This Bravo 4-Zone Package Includes
  • (1) 4-Zone Heat Pump Outdoor Unit (-13°F) — upgradable via drop-down
  • (4) Wall Mount Indoor Units — with remotes + WiFi
πŸ”§ Choose Your Outdoor Unit (BTU by model)
Outdoor Model BTU Zones Min Heat Temp Documents
BRV-M30-230VO 30K 4-Zone -13°F πŸ“„ Cut Sheet πŸ“„ AHRI
BRV-M36-230VO 36K 4-Zone -13°F πŸ“„ Cut Sheet πŸ“„ AHRI
BRV-M42-230VO 42K 4-Zone (tall double-fan) -13°F πŸ“„ Cut Sheet πŸ“„ AHRI
Bravo 30K/36K Outdoor Unit Bravo 42K Tall Outdoor Unit

Note: The BRV-M42-230VO is a tall double-fan configuration. This listing is configured as a 4-zone system.

🧩 Build Your Zones — Read Before Selecting Indoor Units

Important: Do not exceed the outdoor unit's maximum BTU capacity when selecting indoor units. Confirm your selections against the Allowed Combinations document before ordering.

Wall Mount Indoor Units
Bravo Wall Mount Indoor Unit

Wall Mount (Remote + WIFI) • Inverter • Quick heating & cooling • Energy Saving Mode • Night Set Mode • Econo Mode • Louver control • Cooling • Heating • Dry/Dehumidify • Fan Function • Comfort Air-Flow • Timer • Auto Clean • Pre-Heat. Condensate Pump NOT INCLUDED.

Cut Sheets:

4-Way Ceiling Cassette Indoor Units
Bravo 4-Way Ceiling Cassette Indoor Unit

4-Way Ceiling Cassette (Remote + WIFI + Grill): Ceiling cassette indoor units offer 360° coverage, with a built-in condensate pump. These units are perfect for drop ceilings or ceiling applications with enough space to accommodate the body of the unit.

Features: Quiet mode • Turbo mode • Auto mode • Cool mode • Dry mode • Fan mode • Heat mode • FAN function • TIMER ON / TIMER OFF • Child lock • Air function • Health function • WiFi function • LED • Follow Me • Sleep mode

Cut Sheets:

Slim Ducted Indoor Units
Bravo Slim Ducted Indoor Unit

Slim Ducted (Thermostat + WIFI): Slim ducted indoor units offer full coverage, with a built-in condensate pump. These units are perfect for installing in attics, crawl spaces, closets and more. Use these units if you need to run a duct to a bathroom, closet, pantry or any other smaller area where you cannot install a typical indoor unit.

Features: Quiet mode • Turbo mode • Auto mode • Cool mode • Dry mode • Fan mode • Heat mode • X-FAN function • TIMER ON / TIMER OFF • Child lock • Air function • WiFi function • LED • Follow Me • Sleep mode

Cut Sheets:

Floor / Ceiling Indoor Units
Bravo Floor / Ceiling Indoor Unit

Floor or Ceiling Mount (Remote & WIFI): Floor Ceiling indoor units offer a versatile installation, with NO condensate pump. These units are perfect for installing low on the floor against the wall or on a ceiling. Use these units if you do not have the wall space for the typical wall mount.

Features: Quiet mode • Turbo mode • Auto mode • Cool mode • Dry mode • Fan mode • Heat mode • X-FAN function • TIMER ON / TIMER OFF • Child lock • Air function • WiFi function • LED • Follow Me • Sleep mode

Cut Sheets:

Efficiency & Performance (default configuration)

23
SEER2
12.5
EER
10
HSPF
-13°F
Min Heat Temp
R32
Refrigerant
4
Zones
Technical Specifications
System Type Multi-Zone Ductless Split Heat Pump (4 zones)
Factory Fujitsu General
SEER2 Rating 23 (default configuration)
EER Rating 12.5 (default configuration)
HSPF Rating 10 (default configuration)
Refrigerant R32
Voltage 208/230V
Min Heating Temperature -13°F
Min Cooling Temperature -13°F
Default Configuration 4-zone outdoor unit + 4 wall mount indoor units (remote + WiFi)
Upgrade Options Outdoor unit and all indoor units selectable via drop-downs
Outdoor Features Full DC-Inverter; auto restart; auto defrost; heat/cool; R32 refrigerant; compact design; refrigerant leak protection; Bluefin protection; multiple fan speeds; auto-swing louvers; turbo mode / eco mode; comfortable sleep mode; smart app (WiFi)
Warranty 7yr Compressor / 5yr Parts (Registration Required)

πŸ“„ Documents & Resources

Factory: Fujitsu General

Built by a global leader in HVAC manufacturing, engineered for North American homes.

R32 Refrigerant

Uses eco-friendly R32 refrigerant for strong performance with a smaller environmental footprint.

Four Indoor Form Factors

Mix wall mount, 4-way cassette, slim ducted, and floor/ceiling indoor units on the same system.

Full DC-Inverter

Precise inverter control maintains stable room temperature while reducing sound levels and saving energy.

Bluefin Protection

Anti-corrosive Bluefin coil coating resists salt air, rain, and other corrosive elements to extend coil life.

Refrigerant Leak Protection

The system monitors the refrigerant circuit for leaks, protecting the compressor from damage.

Smart App Included

WiFi is included so you can control each zone independently from your smartphone.

Anti-Mildew Mode

Runs a drying cycle after operation to prevent mold and mildew growth inside the indoor unit.

Why Buy From Mini Split Warehouse

Free Nationwide Shipping

No weight limits. No dimensional charges. Free freight delivery on every order.

Factory Warranty Included

Every unit ships with the full manufacturer warranty — no third-party coverage needed.

Lowest Prices Online

We cut out the middleman. Compare us against any competitor — we back our pricing.

20+ Brands Side By Side

Shop Pioneer, Daikin, Midea, MRCOOL, Cooper & Hunter, and more in one place.

Real Technical Support

Call or email our team. We answer specs, sizing, and installation questions — not scripts.

3% Cash Back Offer

Pay by check or bank transfer and get 3% back — one of the easiest savings available.

Trust Badges

βœ… Factory Warranty Coverage

7
Year Compressor
5
Year Parts

*Warranty registration REQUIRED — Register Your System

Frequently Asked Questions

Will my warranty be valid if I don't use a licensed installer?

No. This is a traditional line-set system — brazing, evacuation, and charging the refrigerant circuit must be performed by an EPA 608-certified technician. The manufacturer's warranty also depends on professional installation and online registration. Our team can answer sizing and line-set questions before you order — just call or email.

How do I know which indoor units will work with my outdoor unit?

Check the Allowed Combinations document in the Build Your Zones section for your chosen outdoor model before ordering. As a rule, the combined BTU of your indoor units must not exceed the outdoor unit's rated BTU capacity. Our team can verify your pairing before you order.

How cold can this system heat, and does output drop below that?

The system operates down to -13°F outdoor ambient. As with any air-source heat pump, heating capacity tapers as outdoor temperature falls; a Manual J load calculation is the right way to confirm the system meets your home's heat load at your local design temperature. Our team can help with sizing before you order.

Do the efficiency ratings change if I upgrade the outdoor or indoor units?

Yes. The 23 SEER2 / 12.5 EER / 10 HSPF figures apply to the default configuration — changing indoor sizes, indoor types, or the outdoor unit changes the system's efficiency. Use the AHRI certificates in the outdoor table to verify ratings for a specific pairing.

Specification
Title Bravo 4-Zone 23 SEER2 Mini Split Heat Pump (-13Β°F) WIFI, E-Star: 12.5 EER/10 HSPF (R32)
Brand Bravo
Category Quad. | 4 Zone | Select Four Heads
SKU R32 Bravo (4 Zone Special)
Condition new
UPC 658515761222
MPN BRV-M30-230VO
Reviews 2
4.5 2 reviews

Simple, sleek, and it just works.

Wade Collins · May 2026

Ditching the bulky window units for this setup was a game-changer. The coolest part is how it feels like a ghost is running the climateβ€”you don't hear a thing, but suddenly the air just feels "right." It’s handled everything from sticky heatwaves to freezing nights without breaking a sweat or hiking up the bills. Managing four different rooms from my phone feels like a superpower; I can finally stop arguing about the thermostat and just let every room have its own vibe.

four Rooms

Abel Castellanos · August 2026

This unit cured my home's hot and cold spots in one move. Cools instantly and heats down to -13Β°F. Chopped 30% off my power bill. Easy phone app control for each room. Hire a pro for the multi-line setup, but once it's in, it's pure comfort.

Customer Reviews

4.5 / 5 · 2 reviews
Simple, sleek, and it just works.

Ditching the bulky window units for this setup was a game-changer. The coolest part is how it feels like a ghost is running the climateβ€”you don't hear a thing, but suddenly the air just feels "right." It’s handled everything from sticky heatwaves to freezing nights without breaking a sweat or hiking up the bills. Managing four different rooms from my phone feels like a superpower; I can finally stop arguing about the thermostat and just let every room have its own vibe.

Wade Collins · 2026-05-15
four Rooms

This unit cured my home's hot and cold spots in one move. Cools instantly and heats down to -13Β°F. Chopped 30% off my power bill. Easy phone app control for each room. Hire a pro for the multi-line setup, but once it's in, it's pure comfort.

Abel Castellanos · 2026-08-17
