12000 btu DLFSD Ducted Indoor Unit
Product Code: DLFSDAH12XAK
Brand: Carrier Midea North America
Product Condition: New
KEY FEATURES
- Vertical or Horizontal Installation
Designed for maximum installation flexibility with the built-in secondary drain pan which allows the unit to be mounted vertically for either a floor or ceiling-concealed installation depending on existing conditions. - Built-In Codensate Lift Pump
Supplied with a condensate lift pump that is capable of lifting the water 29.5 in. (750 mm.) above the top of the unit.
FEATURES
- Available in 208/230V
- Up to 22.5 SEER and up to 12.0 HSPF when paired with DLCSR outdoor unit.
- Modes: Cool, Heat, Dry, Fan, Auto
- Vertical or horizontal installation
- Up to 0.64 in WG
- Rear or bottom return
- Constant CFM operation
- Built-in condensate lift pump
- Follow Me (senses temperature at optional handheld remote)
- Heating Setback (46° F Heating Mode)
- Quiet indoor operation, as low as 30 dB(A)
- Aluminum Golden Hydrophilic pre-coated fins
Compatible With:
- DLCSR Outdoor Unit Single Zone
- DLCMRA Outdoor Unit Multi-Zone
Color: None
DLFSDA Ducted | ||
Heat Pump | ||
System | ||
Size | 12 | |
Indoor Model | DLFSDAH12XAK | |
Electrical | ||
Voltage-Phase-Cycle | V-Ph-Hz | 208/230-1-60 |
Power Supply | Indoor unit powered from outdoor unit | |
MCA | A. | 1.11 |
Operating Range | ||
Cooling Indoor DB Min - Max | ° F (° C) | 62~90 (17~32) |
Heating Indoor DB Min - Max | ° F (° C) | 32~86 (0~30) |
Piping | ||
Pipe Connection Size - Liquid | in (mm) | 1/4 (6.35) |
Pipe Connection Size - Suction | in (mm) | 1/2 (12.7) |
Indoor | ||
Unit Width | in (mm) | 27.56 (700) |
Unit Height | in (mm) | 7.87 (200) |
Unit Depth | in (mm) | 19.92 (506) |
Net Weight | lbs (kg) | 43.56 (19.8) |
Number of Fan Speeds | 3 | |
Airflow (lowest to highest) | CFM | 176/282/353 |
Sound Pressure (lowest to highest) | dB(A) | 35/37/39 |
Max. Static Pressure | in (WG) | 0.20 |
Field Drain Pipe Size O.D. | in (mm) | 1 (25.4) |
